Addionol hydraulic oil HLP 100

Addionol hydraulic oil HLP 100

€1.179,55 EUR
€1.179,55 EUR
Sale Sold out
Taxes included. Shipping calculated at checkout.
Lieferzeit: Aufgrund der aktuellen Marktsituation nennen wir Ihnen den genauen Liefertermin verbindlich mit der Auftragsbestätigung.

Inquiries

ADDINOL Hydraulic Oil HLP 100 is a high-quality hydraulic oil manufactured from selected mineral oil raffinates and a zinc-containing additive combination. This composition ensures improved aging behavior, optimal wear protection, and excellent corrosion protection. The oil is particularly suitable for industrial and mobile hydraulic systems operating at high pressures and meets the requirements of DIN 51524-2 (HLP).

Advantages for the user:

  • Excellent demulsifying and water-separating properties – protection against penetrating water.
  • Excellent air release capacity and low foaming tendency – reduction of foam formation
  • Good compatibility with sealing materials and paints – leaks are avoidable.
  • Excellent wear protection properties – trouble-free operation even in multi-metal systems
  • High thermal-oxidative stability – extended oil change intervals
  • Versatile applications – reduces the risk of misuse
  • Good filterability – high purity

Specifications and approvals:

  • DIN 51524-2 (HLP)
  • DIN EN ISO 6743-4 (HM)
  • DIN 51517-2 (CL)
  • ISO 6743-6 CKB (ISO VG 32 to ISO VG 100)
  • Bosch-Rexroth RE 90220 (ISO-VG 22 to ISO VG 100)
  • Viscosity classification according to DIN ISO 3448

Technical data ADDINOL hydraulic oil HLP 100

feature Test conditions / unit HLP 100 Testing procedure
ISO viscosity class - 100 ISO 3448
Density at 15°C kg/m³ 881 DIN 51757
Viscosity at 0°C mm²/s 1750 ASTM D 7042
Viscosity at 40°C mm²/s 99.1 ASTM D 7042
Viscosity at 100°C mm²/s 11.1 ASTM D 7042
Viscosity index - 97 DIN ISO 2909
Flash point COC °C 270 DIN EN ISO 2592
Pourpoint °C -22 ASTM D 7346
Air separation efficiency at 50°C minutes < 12 DIN ISO 9120
Demulsifying properties minutes 5** DIN ISO 6614
FZG damage force level - ≥ 12 ISO 14635-1
vane pump - passed DIN 51389-2
Oxid ash % < 0.15 DIN EN ISO 6245
Aging behavior (NZ 1000h) mg KOH/g < 1.5 DIN EN ISO 4263-1
Corrosion protection for steel - passed DIN ISO 7120
Corrosive effect on copper Correction grade 1 DIN ISO 2160
Foaming behavior at 24°C ml/ml < 20 / 0 ASTM D 892
Foaming behavior at 93.5°C ml/ml < 20 / 0 ASTM D 892
Foaming behavior after 93.5°C ml/ml < 20 / 0 ASTM D 892
