Description: Shell PANOLIN S4 HLP Synth 46 is a high-performance, readily biodegradable hydraulic fluid based on saturated synthetic esters. It is part of the industry-leading range of biodegradable saturated ester (HEES) synthetic hydraulic fluids and the first Bosch-approved HEES fluid. Formulated with high-performance, synthetic saturated esters, its special zinc-free additive technology offers increased machine efficiency through improved oil life and superior wear protection. It is particularly suitable for use in environmentally sensitive applications such as stationary and mobile hydraulic systems in construction, agriculture, and forestry.
Characteristics:
- Extended service life: Shell PANOLIN S4 HLP Synth offers extended oil life, supporting continuous, uninterrupted operation of machinery and equipment. Longer oil change intervals mean less oil needs to be produced, purchased, and disposed of. Excellent TOST test results of over 6,000 hours (modified ASTM D943 test).
- Improved wear protection: Provides exceptionally high wear protection for hydraulic equipment and strong protection against sludge and varnish deposits.
- Efficient in cold climates: Good low-temperature performance enables reliable starting even at low temperatures and reduces the risk of metal-to-metal wear. Shear-stable fluids with a high viscosity index protect the machine over a wide temperature range and enable higher hydraulic efficiency compared to standard HM mineral oil.
Specifications, approvals & recommendations:
- ISO 15380:2016 HEES
- Meets the requirements of ISO 4263-3
- Biodegradable according to OECD 301B >60%
- Japan Eco Mark
For a list of all OEM approvals and recommendations, please contact your Shell representative.
Typical characteristics:
| Characteristic | method | Shell PANOLIN S4 HLP Synth 15 |
|---|---|---|
| ISO fluid type | ISO 6743-4 | HEES |
| Kinematic viscosity @-20 °C (mm²/s) | ASTM D445 | 520 |
| Kinematic viscosity @40 °C (mm²/s) | ASTM D445 | 15.6 |
| Kinematic viscosity @100 °C (mm²/s) | ASTM D445 | 3.9 |
| Viscosity index | ASTM D2270 | 147 |
| Density @15 °C (kg/m³) | ASTM D4052 | 925 |
| Flash point (°C) | ASTM D92 | 222 |
| Color | Visually | clear amber |
| Demulsification capacity @54 °C (minutes) | ASTM D1401 | 5 |
| TOST test (hour minimum) | ASTM D943 | 6000 |
| Pour point (°C) | ASTM D97 |
-60 |
Health, safety and environmental information:
- Health and Safety: When used properly, no risk to safety and/or health. Avoid skin contact and wear impermeable gloves when handling used lubricants. Clean your skin immediately with soap and water after contact. For further information, see the safety data sheet at www.shell.de/datenblaetter .
- Protect the environment: Take used lubricants to an authorized collection point. Do not dispose of them in sewers, soil, or waterways.
